Product Features
- Durable Stainless Steel Construction: The pass window is made of high-quality stainless steel, ensuring resistance to rust and durability.
- Electronic Interlock System: The electronic interlock system prevents both doors from being opened simultaneously, ensuring no contamination between clean and non-clean areas.
- Double-Layer Glass Doors: Equipped with double-layer glass doors, which are smooth, easy to clean, and resistant to dust accumulation.
Applications
- Pass windows are ideal for use in environments requiring air purification, such as microelectronics labs, biological laboratories, pharmaceutical factories, hospitals, food processing, LCD, and electronics manufacturing industries.
SPECIFICATIONS
| Number | Name | Specifications |
|---|---|---|
| ① | Product Material | Galvanized sheet coating on the outer shell, stainless steel coating on the inner wall |
| ② | Single door opening | 1.0mm galvanized sheet, double-layer insulated tempered glass |
| ③ | Air supply system | Wind speed 25m/s |
| ④ | Efficient filter | 2 pieces |
| ⑤ | Primary filter | 2 pieces |
| ⑥ | Lighting | 9W LED fluorescent lamp |
| ⑦ | Stainless steel nozzle | 6/12/16 pieces, adjustable in 360 degree direction |
| ⑧ | Control system | Microcomputer control system, touch buttons, human body sensing |
| ⑨ | Power Supply and Power | 380V 50Hz 1.6Kw |
| ⑩ | Cleanliness level | 100000 level |
