Product Features
- The unit adopts a double-row sunken track structure to optimize the convenience of installation, commissioning and maintenance. The replaceable small track structure makes maintenance simpler. The downward-flipping chassis cover plate enables quick troubleshooting and maintenance.
- The sealing strips are adopted to maintain airtightness (meeting international airtightness standards) in negative or positive pressure environments (such as operating rooms, isolation wards, PCR laboratories), preventing cross-contamination.
- The door body is mostly made of stainless steel, antibacterial coating or anti-corrosion composite materials, with a smooth and seamless surface, which is convenient for disinfection.
- It can meet the functional requirements of any occasion through various opening and closing methods (such as foot sensors, elbow switches, hand sensors, access control switches, etc.).
- Humanized barrier-free design ensures the safe passage and convenient use of patients and trolleys, providing the greatest possible convenience.
Application Areas
It is applied in operating rooms, medical clean rooms, laboratories, food/drug work-shops, ICU wards, etc.
SPECIFICATIONS
| Parameter | Specification | Parameter | Specification |
|---|---|---|---|
| Net dimensions of the door opening | 600-2200mm(single door available) | Opening hours | Adjustable from 0 to 9 seconds |
| 1200-3000mm(Double door available) | Closing force | >70N | |
| The running speed for opening and closing the door | 300-600mm(adjustable when opening the door) | Manual thrust | ≤50N |
| 300-600mm(adjustable when opening the door) | Power supply voltage | AC200V-250V 50/60Hz | |
| Electric control drive | Dc brushed motor | Power consumption of the whole machine | <180W |
| Dc brushless motor | Air tightness | Conform to international standards |
